Horizontal Hinge Holes Drilling Machine Features:
- Hinge Combination Drilling Machine is special to drill the holes in the side of aluminum profile.
- Can drilling 4 holes in each side and one cycle time finish when load the profile.
- Work with the multi drill adapter give more procession in the drilling work, special for the hige hole drilling on the out casement sash.
- High technology improves the working efficiency to solve the problem of low accuracy.
Hinge Combination Drilling Machine Technical Parameters:
| 1 | Voltage | 380V 50Hz |
|---|---|---|
| 2 | Power | 4.5Kw |
| 3 | Air Pressure | 0.6-0.8Mpa |
| 4 | Air Consumption | 75L/min |
| 5 | Process Width | 1800mm |
| 6 | Drilling Diameter | 3-11mm |
| 7 | Hole Distance | 22-200mm |
| 8 | Motor Rotate Speed | 2800rpm |
| 9 | Dimension | 3100x1200x620mm |
Hinge Holes Drilling Machine Advantage:
The Combination Hinge Holes Drilling Machine is for hinge hole drilling of an aluminum window and door. The two horizontal heads can be used to drill multi holes in a line at one cycle time. So it only drill the multi holes at one time while loading a complete window sash. Due to using the multi-drill adapter, the drill bits distance canbe adjustable. So it can fit for any type hinge using after drill. This machine is very effective for ensuring that a hole is drilled perfectly.
The Combination Hinge Holes Drilling Machine’s chuck mechanism consists of a generally rectangular block supported on a pair of horizontally spaced parallel rods. Its chuck mechanism is mounted forward of the 4 or 5 drill bits at each side. The holes position and distance will be setting according to the hinge. So after drill the hinge will be well fit in the window sash.
The drill bit’s pattern of this two side aluminum profile drilling machine must match the hinge’s position. The drill should be positioned in the exact position, while the aperture should be the right size. It should not be repeated on the surface of the profile. Generally, the machine increase the great efficient of the hinge holes drill work, no need manual drill anymore. The machine will help you to finish it automatically.
Hinge Combination Drilling Machine is the most versatile and reliable way to drill hinge holes in aluminum windows and doors. They can be configured to drill various types of materials and can also be customized for different applications. They come in a variety of designs, and can be configured to suit the specific needs of a particular job. In addition to horizontal drilling, horizontal machines are useful for drilling more holes request on the window profiles.
